Mcfk Carbon Road Aero Handlebar – 31.8mm – UD Matte



Mcfk – Stable – Lightweight – Ergonomic – Comfortable

These four properties had to be brought together in the development of the new carbon racing bike handlebar. Mcfk is proud of the result! The stability is as usual from this company and unimpeachable, and the outstanding stiffness values ensure utmost transmission of force in spring situations.

Considering the bar width of 380 mm, oversize clamp and the available stability level, this is one of the most light-weight series handlebar in the market.
The Mcfk sophisticated ergonomics concept permits long rides with your hands on the bottom bars without higher stress for your neck and back. 130mm drop and 77mm reach ensure best control of your racing bike at all times. The bottom bar is turned outside 4°, which has a noticeably positive effect when riding out of the seat.

Mcfk Road Aero Bar Geometry:

• Width: 380mm, 400mm, 420mm or 440mm (center – center)
• Width (under bar end): 430 mm / 450 mm / 470 mm / 490 mm (outside – outside)
• Drop: 130mm
• Reach: 77mm
• Diameter Top: 31.8mm
• Top angle: 5°
• Lever angle: 2°
• Drop angle: 4°
• Max. rider weight: 100 kg
• Di2 compatible: yes

Weight*

380mm: 159g
400mm: 162g
420mm: 465g
440mm: 168g

* 5% range of tolerance, manufacturer information
